High-precision laser cutting tube OR-TA
Place the pipe on the supporting roller
The pipe clamping range is wide,Round tube φ10-φ10, and Square tube side length is 10 * 10mm-350mm * 350mm. Support the cutting of various shapes of pipe materials, such as I-beam, channel steel, angle steel, elliptical pipe, waist pipe, multi-deformed pipe, etc.
Pneumatic correction and centering device
Place the pipe on the supporting roller, the correction component works, and the correction device clamps the pipe to automatically align the center of the chuck, and the chuck precisely clamps and feeds the material.
Integrated Machine Bed
Adopt overall heavy-duty high-strength cold-rolled tube sheet tailor-welded bed, plug-in structure, and equal-strength welding
Upgrade the tube cutting bus system
Cypcut FSCUT5000 pipe cutting bus system supports high-precision and high-efficiency cutting of square pipes, round pipes, racetrack-shaped, elliptical and other stretched pipes, as well as angle steel and channel steel.
Efficient Auto-lubrication system
Manually set the number and time interval of automatic lubrication according to the length of equipment use;Automatic lubrication of guide rails, sliders, gears, racks, and other components, recycling, and centralized processing of lubricating waste oil.
