Automatic Solid Phase Extraction – SPE100/200/400
As the latest multifunction microwave chemistry reaction platform of SINEO Microwave Chemistry Technology Co., Ltd, MAS-II Plus microwave synthesis/extraction reaction workstation, that can meet various experiment plans, has a rational, friendly and simple operation design. It is widely used in researches, such as organic synthesis, pharmaceutical chemistry, organic extraction, food science, analytical chemistry, inorganic chemistry, protein research,petrochemical engineering and materials chemistry, etc. MAS-II Plus supplies a versatile reaction platform that is superior to regular heating method.
Description
| SPE100/SPE200/SPE400/SPEX00(Customization) | |
| Channels | 1/2/4/X |
| Channel Independent Control | Support |
| Sample pump | Precision Continuous Sample Pump |
| Pump flow rate | 0.1-120mL/min |
| Types of solvents | 8Seed, 500 mL Solvent Bottle |
| Sample volume | 0.1mL-20L |
| Sample tube volume | 10 – 20 mL,customization |
| Receiving volume | 10mL/15mL, other specifications customized |
| Puncture sampling | Supporting |
| Loading mode | X/Y/Z Three-Dimensional Manipulator |
| Accuracy of manipulator | 0.01mm |
| Sealing technology | Docking Technology of Independent Seal Cover and Pan-plug Seal |
| Extraction mode | Positive pressure extraction |
| column pressure | ≦80psi |
| Pressure sensing | Support, Overvoltage Alarm, Threshold Editable (5-145psi) |
| Column drying method | Nitrogen purge |
| Waste collection | Branch collection，3 channels |
| A/B in series | Support, A/B Pillar |
| Cleaning mode | Nitrogen purge, solvent cleaning, blowing stirring cleaning and other modes are used to clean the inner and outer walls of sample needles. |
| Liquid level following | Support |
| Solvent Residual Capacity | Solvent deficiency hints |
| Host Size (H*W*D) | 680mm x 580mm x 670mm |
| Voltage | 220/110V，50/60Hz |
| working temperature | 5-40Temperature |
| Working humidity | 0-90% without condensation |
| power | 60W/80W/120W/<200W |
